Power Telemetry Module

Overview

A high-current DroneCAN power monitor for UAVs and robotic platforms. Measures battery voltage, current, power consumption, energy usage, and system temperature while providing real-time telemetry to compatible flight controllers.

Key Features

Supports 2S–14S Li-ion / LiPo
Up to 58.8 V at 14S full charge
50 A continuous monitoring
100 A peak current
High-side shunt (0.5 mΩ, 4-terminal Kelvin)
16-bit V / I / P / E telemetry
DroneCAN v0
ArduPilot & PX4 compatible
Reverse-battery protection
Firmware-configured calibration
< 1 W module power

12S ESC Controller

Overview

High-performance electronic speed controller for multirotor UAVs and robotic platforms. Designed for high reliability, thermal performance, and efficient motor control.

Key Features

1 channel BLDC motor output
Supports 6S–12S LiPo
Up to 60 A continuous
75 A burst per motor
High-efficiency MOSFET stage
Current sensing
Temperature monitoring
14.5 g target weight
AM32 firmware
DShot300/600
Bidirectional DShot
PWM Control
KISS telemetry
Low-EMI layout
60 × 30 mm PCB
30.5 mm mounting pattern

Made in USA

NDAA Compliant
